Beitian M10 Ultra-Low Power GNSS GPS Module for Vehicle and Drones

The Beitian M10 GPS module is an ultra-low power GNSS receiver designed for vehicles, drones, and fixed-wing planes. It supports multiple satellite systems and is compatible with popular flight control hardware.

• Chip: U B X M10050
• Satellite Systems: GPS L1 C/A, QZSS L1 C/A/S, BDS B1I/B1C, Galileo E1B/C, SBAS L1 C/A (WAAS, EGNOS, MSAS, GAGAN)
• Operating Modes: GPS+BDS+GALILEO+SBAS+QZSS
• Position Accuracy: 1.5 m CEP 2D RMS with SBAS assistance (open sky)
• Speed Accuracy: 0.05 m/s
• Dynamic Heading Angle Accuracy: 0.3 degrees
• Output: TTL level signals, baud rate 4800–921600 bps (default 38400 bps), protocols NMEA and UBX
• Update Frequency: 0.25 Hz to 18 Hz (default 1 Hz)
• Power Supply: DC 3.6 V to 5.5 V (typical 5.0 V), current 50 mA at 5.0 V
• Operating Temperature Range: -40 °C to +85 °C
• Compatibility: Works with Arduino, Raspberry Pi, Pixhawk F3, CC3D, Betaflight F4 flight controllers
